GDY 20.0 | 20.0kVA Diesel Generator

A highly mobile skid or road tow diesel powered generator, delivering stable and powerful multi-voltage output. Fitted as standard with a long-run bunded fuel tank, silenced acoustic enclosure and easy access maintenance with a twin split cabinet. The diesel engine is EU Stage V Emission Standards compliant, suitable for use with HVO alternative fuel and comes with the options of spark arrestors and Chalwyn style air intake valves.

Yanmar 4-cylinder 1500RPM
20kVA 400V – 3 Phase, 10kVA 220V and 5kVA 110V single phase
Socket outlets configurable on application
AVR Voltage regulation
Acoustic Canopy, skid base with fork pockets, bunded fuel tank
Optional Road Tow kit available
Spark arrestor & air intake valve shut down options
3-Yr Warranty

GDY20 BACK LR



Full Training
& Set Up



Nationwide
Delivery



UK Network For Local Support & Aftercare



3 Years Warranty as Standard



Full Training & Set Up



Nationwide Delivery



UK Network For Local Support & Aftercare



3 Years Warranty as Standard

Spec Overview

GDY 20.0/3-AVR

Engine: Yanmar Diesel 4-Cyclinder 1500rpm - Electric Start

Welder:

Aux Power: 110/230 & 400V AC - 20.0kVA

Length: 1950mm

Width: 860mm

Height: 1120mm

Download FULL Datasheet

Spec Overview

GDY 20.0/3-AVR

Engine: Yanmar Diesel 4-Cyclinder 1500rpm - Electric Start

Welder:

Aux Power: 110/230 & 400V AC - 20.0kVA

Length: 1950mm

Width: 860mm

Height: 1120mm

Download FULL Datasheet
